Specialized inFC2842125 Four Row Cylindrical Roller Mill Rolling Bearingand related product development and production

Samples: Available / Stock: Sufficient
Estimated delivery time: 3-5 days
FC2842125 Four Row Cylindrical Roller Mill Rolling Bearing
FC2842125 Four Row Cylindrical Roller Mill Rolling Bearing - 图片 2
FC2842125 Four Row Cylindrical Roller Mill Rolling Bearing - 图片 3
FC2842125 Four Row Cylindrical Roller Mill Rolling Bearing - 图片 4

Product Parameters

Customization: Available Rolling Body: Roller Bearings The Number of Rows: Four Row

Basic Info.

Model NO.
FC2842125

Outer Dimension
Large (200-430mm)

Material
Bearing Steel

Spherical
Non-Aligning Bearings

Load Direction
Radial Bearing

Separated
Separated

Product Name
Four Row Cylindrical Roller Mill Rolling Bearing

Cage Material
Brass / Steel

Basic Dynamic Load Rating (C) - 108 Kn
640 Kn

Basic Static Load Rating (Cor)
1440 Kn

(Grease) Lubrication Speed
2200 R/Min

(Oil) Lubrication Speed
2800 R/Min

Weight
14.9kg

Inner Ring Weight
4.1 Kg

Certificates
ISO9001,SGS

Key Words
Mill Rolling Bearing

Samples
Available

Transport Package
Single Box / OEM

Specification
140x210x125mm

Trademark
TFN / OEM

Origin
Shandong, China

HS Code
8482500090

Production Capacity
99999999 PCS /Month

Product Description


FC2842125 Four Row Cylindrical Roller Mill Rolling Bearing


Details of Mill Rolling Bearing

Four-row cylindrical Mill Rolling Bearings are available in several designs:

with a cylindrical or tapered bore
open or sealed

Four-row cylindrical roller bearings are used almost exclusively for the roll necks of rolling mill stands, calenders and roller presses. Because they are normally mounted with an interference fit on the roll neck, four-row cylindrical roller bearings are well suited for rolling mill applications where the rolling speed is high.

Because four-row cylindrical roller bearings can accommodate only radial loads, they are mounted together with deep groove or angular contact ball bearings, or with tapered roller bearings (either radial or thrust design) which accommodate the axial loads.

Bearing features
Exceptional high load carrying capacity

Because of their high number of rollers, four-row cylindrical roller bearings are suitable for very heavy radial loads.

Low friction (Roller end / flange contact area)

The open flange design, together with the roller end design and surface finish, promote lubricant film formation resulting in lower friction.

Long service life

The logarithmic roller profile reduces edge stresses at the roller/raceway contact and sensitivity to misalignment and shaft deflection.

Enhanced operational reliability

The surface finish on the contact surfaces of the rollers and raceways supports the formation of a hydrodynamic lubricant film.

Separable and interchangeable

The separable components of SKF four-row cylindrical roller bearings are interchangeable. This facilitates mounting and dismounting, as well as maintenance inspections.

High speed capability

The cage designs are suitable for high speeds, rapid accelerations and peak loads.

Low cross-sectional height

The low cross-sectional height of four-row cylindrical roller bearings allows for relatively large roll neck diameters compared to the roll diameter.

FC2842125 Four Row Cylindrical Roller Mill Rolling Bearing

FC2842125 Four-row cylindrical roller bearing 140x210x125mm(also called rolling mill bearing) is used in rolling mill for the production of steel plates, hot-rolled and cold-rolled strips/coils, hot-rolled bars, rods, tube rounds, structural shapes and rails.



Boundary dimensions(mm) Basic load ratings (kN) Speed rating Designation Weight(kg)
(rpm)
d D B Fw rmin Cr Cor Grease Oil Complete set Inner ring
140 210 125 158 2 640 1440 2200 2800 FC2842125 14.9 4.1



Product Name FC2842125 Four Row Cylindrical Roller Mill Rolling Bearing

Dimension

140x210x125mm

Model Number

 FC2842125

Material

Gcr15/ Carbon Steel/ Stainless Steel/ Si3N4/ ZrO2

Cage

Steel/ Brass/ Nylon/ Custom

Closures

Open, ZZ,2RS ,RZ,

Types

N, NU, NJ, NF, NUP, NCF,NN, NNU, FC, FCD, FCDP, NNCF,NNF,SL etc

For non standard bearing,there are many different types with various sizes for our

clients and we can alsodesign or develop customized products as per the samples

or drawings provided by our clients.

Precision

P0, P6, P5, P4, P2 or as requested

Vibration

ZV1, ZV2, ZV3, or as requested

Clearance

C0,C2,C3, or as requested



Ohter Cylindrical Roller Bearing Models :

Model no d(mm) D(mm) T(mm) W(KG)
NU204 20 47 14 0.11
NU205 25 52 15 0.137
NU206 30 62 16 0.211
NU207 35 72 17 0.30
NU208 40 80 18 0.382
NU209 45 85 19 0.438
NU210 50 90 20 0.493
NU211 55 100 21 0.648
NU212 60 110 22 0.84
NU213 65 120 23 1.07
NU214 70 125 24 1.16
NU215 75 130 25 1.25
NU216 80 140 26 1.5
NU217 85 150 27 2.5
NU218 90 160 30 2.35
NU219 95 170 32 2.8
NU220 100 180 34 3.42
NU221 105 190 36 4.07
NU222 110 200 38 4.73
NU224 120 215 40 5.65
NU226 130 230 40 6.5
NU228 140 250 42 8.2
NU230 150 270 45 10.4
NU232 160 290 48 14.4
NU234 170 310 52 17.7
NU236 180 320 52 18.4
NU238 190 340 55 22.3
NU240 200 360 58 26.6
NU244 220 400 65 37.3
NU248 240 440 72 50.5
NU252 260 480 80 67.1

FC2842125 Four Row Cylindrical Roller Mill Rolling Bearing

Packing of Mill Rolling Bearing

FC2842125 Four Row Cylindrical Roller Mill Rolling Bearing

Certificates of TFNbearing
FC2842125 Four Row Cylindrical Roller Mill Rolling Bearing

Advantages of TFNbearing
FC2842125 Four Row Cylindrical Roller Mill Rolling Bearing



FAQ of Mill Rolling Bearing

1.Q:Are you a factory or trading company?

   A:TFN Bearing is specialized in manufacturing and exporting bearings.

      TFN Bearing have own factory and warehouse.

2.Q:Can I get some samples and do you offer the sample free?

   A:Yes, sure, TFN Bearing are honored to offer you samples.Can you buy a ticket ?

3.Q:What is the payment?

   A: 30% T/T In Advance, 70% T/T Against Copy Of B/L

   B: 100% L/C At Sight

4.Q:What is the MOQ for bearing?
   A: TFN Bearing MOQ is 1 pc.

5.Q:What kind of service you can offer?

   A:Technology support;Installation guidance;OEM.

6.Q:You only can supply four row Cylindrical roller bearing / Mill Rolling Bearing ?

   A:No,we also can supply double row Cylindrical roller bearing, single row Cylindrical roller bearing,also inch Cylindrical roller bearing
