Specialized inTtsx120 Full Complement Bearings for Rolling Mill Pressing Mechanismand related product development and production

Samples: Available / Stock: Sufficient
Estimated delivery time: 3-5 days
Ttsx120 Full Complement Bearings for Rolling Mill Pressing Mechanism
Ttsx120 Full Complement Bearings for Rolling Mill Pressing Mechanism - 图片 2
Ttsx120 Full Complement Bearings for Rolling Mill Pressing Mechanism - 图片 3
Ttsx120 Full Complement Bearings for Rolling Mill Pressing Mechanism - 图片 4

Product Parameters

Customization: Available Contact Angle: 0 Aligning: 0

Basic Info.

Model NO.
TTSX120

Separated
Separated

Rows Number
Single

Load Direction
Radial Bearing

Material
Bearing Steel

Product Name
Ttsx120 Full Complement Bearings

Width
45 mm

Bore Diameter
120mm

Outside Diameter
120mm

Certificate
ISO9001:2008

Application
Machinery

Main Markets
Global

Package
Original Package

Stock
Large

Weight
3.3 Kg

Transport Package
1.Industrial Packaging: Plastic Tube (10PCS in One

Specification
47.625 x 95.25 x 30.162mm

Trademark
TFN

Origin
Shangdong China

HS Code
8482400000

Production Capacity
5000000/Year

Packaging & Delivery

Package Size
120.00cm * 50.00cm * 120.00cm

Package Gross Weight
4.000kg

Product Description

TTSX120 Full complement Bearings for rolling mill pressing mechanism
Ttsx120 Full Complement Bearings for Rolling Mill Pressing Mechanism


Product Name

 TTSX120 Full complement Bearings for rolling mill pressing mechanism

Brand

TFN / OEM

Model Number

 TTSX120

Ring Material

Steel

Cage Material

Steel

Precision

P0, P6, P5, or as requested

Vibration

ZV1, ZV2, ZV3, or as requested

Clearance

C0,C2,C3, or as requested

Type

  302 series,303 series,313 series,322 series,323 series,329 series,331 series

Features

Low friction ,Long service life ,Enhanced operational reliability ,Consistency of roller profiles and sizes ,Rigid bearing application,Running-in period with reduced temperature peaks ,Separable and interchangeable.

Quality standard

ISO9001:2000/ SGS

Quality Control Process

1.Assembly

2.Windage test

3.Cleaning

4.Rotary test

5.Greasing and gland

6.Noise inspection

7.Appearance inspection

8.Rust prevention

9.Product packaging

Application

single row tapered roller bearings are designed to accommodate combined loads, i.e. simultaneously acting radial and axial loads. The projection lines of the raceways meet at a common point on the bearing axis to provide a true rolling action and therefore low frictional moments during operation. The axial load carrying capacity of tapered roller bearings increases with increasing contact angle α. The size of the contact angle, which is usually between 10° and 30°, is related to the calculation factor e ,the larger the value of e, the larger the contact angle.

Other taper roller  bearing models :

Dimensions (mm)         Static Load Rating weight Number   FAG
D  D1 T T1 d1 R M
100 98 37 32 87 250 8     TTSX100
120 118 45 38 105 300 10 1365 3.3 TTSX120
150 148 55 47 127 457 12 2325 6.3 TTSX150   536626
150 148 55 47 127 550 12 2325 6.3 TTSX150K
150 148 48   127 228.6 12 2325 5.7 TTSV150
175 173 62 53 152 457 12 3223 9.6 TTSX175   537778
175 173 62 53 152 550 12 3223 9.7 TTSX175K   543535
175 173 53   152 228.6 12 3223 8.5 TTSV175
203 201 75.6 65 178 508 12 4500 16 TTSX203 353108A
203 201 76 65.4 170.8 508 12 4500 16.2 TTSX203K
203 201 85 65 170 250 12 4500 17 TTSX203K1
203 201 65   178 254 12 4584 10.2 TTSV203   536716
205 203 76 65 178 508 12 4585 16.2 TTSX205
205 203 65   178 254 20 4585 14.3 TTSV205
235 233 85 73 208 560 20 6028 23.7 TTSX235
235 233 73   208 280 20     TTSV235
265 263 95 81 229 609 20 7753 33.9 TTSX265 353038A 522978
265 263 81   229 304.8 20     TTSV265   524088
320 318 112 95 , 280 762 20 11500 58.9 TTSX320 353065B 525469
320 318 122.7 95 280 470 20 11500 62.1 TTSX320K
320 318 118.5 95 280 550 20     TTSX320K1
320 318 95   280 381 20 11500 51 TTSV320
330 328 95   280 381 20 11500 51.4 TTSV33K
377 375 129 112 330 914 24     TTSX377 353107A 534470
377 375 129 112 330 930 24 16044 94.7 TTSX377K
377 375 112   330 457.2 24     TTSV377   524578
380 378 129 112 330 914.4 24     TTSX380
380 378 112   330 457.2 24     TTSV380
410 408 142 122 355 1016 24     TTSX410 353058B 524192
410 408 122   355 508 24     TTSV410   533632
440 438 152 130 380 1016 24     TTSX440   517113
440 438 130   380 508 24 23330 137
495 492 172 146 432 1066.8 24     TTSX495 353024B 517982
495 492 146   432 558.8 24     TTSV495
525 522 180 155 460 1270 24 36202 266 TTSX525 353020A 517979
525 522 155   460 635 24     TTSV525   524105
555 552 192 165 482 1270 24     TTSX555   524340
555 552 165   482 635 24     TTSV555   527795
580 577 165   510 710 24 41560 300.6 TTSV580 616674
581 579 193.777 168.275 508 1422.4 24 38984 338 THR581XY 353124A 531065
610 607 205 178 533 1524 30     TTSX610 353093A 526199
610 607 178   533 762 30     TTSV610
640 637 214.5 185 550 1520 30 48560 454 TTSX640 BFSD353134 526198
640 637 185   550 762 30 49200 418 TTSV640   549498
710 705 250 210 610 1600 30     TTSX710
710 705 250 205 610 1400 30 62703 647 TTSX710K
,
750 745 260 225 650 1600 30 63900 747 TTSX750
800 795 270 245 700 1700 30     TTSX800
900 896 280 236 750 1800 36 94000 1150 TTSX900 97350



Ttsx120 Full Complement Bearings for Rolling Mill Pressing Mechanism



Certificate
Ttsx120 Full Complement Bearings for Rolling Mill Pressing Mechanism

PackingTtsx120 Full Complement Bearings for Rolling Mill Pressing Mechanism

FAQ

Q:Why choose us?

A:1. We are professional,have factory in shandong for many years.

   2. We are experienced for 10 years.

   3. We can offer a various kind of bearing with high quality:Z1V1,Z2V2,Z3V3 and best price



Q:How is the quality of your products?

A:The same quality, we have lower price.The same price,we have better quality.



Q:Except Taper Roller Bearing what other main bearing do you have?

A: Deep groove ball bearing,Cylindrical roller bearing,Thrust roller bearing,Spherical roller bearing,Angular contact      ball bearing etc.



Q:Can I get HM801346 X/2/310/Qvq495  free samples?

A:We will charge a little sample fee for our regular designs or customized ones, These charges will be refunded to you when your mass production order is

confirmed.



Q:Can you make the products as our requirement?

A:We have more than 10years' OEM experience. We supply products fo more than 300 automobile parts factories.
